Test instruments

Digital eddy current test instruments with unique functions
The new ibg family of digital eddy current test instruments, with unique technology innovations, provides a simultaneous 100% inline test at an up to now unknown level of test reliability. Detection of grinder burn and cracks, as well as structure changes of the parts can be carried out directly in your production lines. Clear user guidance, an identical operating concept on all instruments and several operating languages will make it easy to make the most of our instruments. Whether it is the modular eddyvisor, the compact eddyliner or the top hat rail assembled eddyguard – we have the right solution for each task.

Structure test

Digital eddy current test instruments for non-destructive testing of metal components, mass-produced parts and semi-ﬁnished products using Preventive Multi-Filter Technology (PMFT). A comparative test for material properties such as hardness, material, tensile strength, heat treatment or alloy. The new ibg family of digital structure test instruments distinguishes itself with the well-proven Multi-Frequency Technology and ibg’s good-part-only-concept, furthermore the Simultaneous Harmonic Analysis iSHA and the optional temperature-adaptive structure test iTAS, both unique ibg innovations, offer enhanced opportunities for eddy current structure testing.

eddyvisor S

2 – 32 structure test channels

eddyliner S

1 structure test channel

eddyguard S

1 structure test channel,
DIN rail mounting

Crack & grinder burn detection

Digital eddy current test instruments for non-destructive testing of metal components, mass-produced parts and semi-ﬁnished products for cracks, pores and grinder burn using Preventive Multi-Filter Technology (PMFT). The new ibg family of digital crack detection instruments offers first a simultaneous 100% inline detection of grinder burn and cracks in your production lines. Due to automatically generated 360° tolerance zones, testing up to 30 simultaneous band pass filters and ibg’s good-part-only concept you will also detect defects which are missed by conventional instruments with a failure-oriented setup.

eddyvisor C

2 – 16 crack testing channels

eddyliner C

1 crack test channel

eddyguard C

1 crack test channel,
DIN rail mounting

Crack / grinder burn detection and structure test in one

Digital eddy current test instrument for non-destructive testing of components, mass-produced parts and semi-ﬁnished products for cracks, pores and grinder burn and for material properties such as hardness, case depth, structure, tensile strength, heat treatment or alloy using Preventive Multi-Frequency Technology. High performance modular concept with max. 16 independently working crack detection channels, max. 32 structure test channels and combinations of that in only one device. The eddyvisor SC is recommended whenever you need an instrument to carry out inline test with several stations, both for crack and structure test.

eddyvisor SC

2 – 32 structure test channels,
2 – 16 crack test channels
or a combination of them
